Cubo 15

Hi,

I am looking at drivers for my 12V rig and have come across the Oberton 15B450, the EBH is 158 so looks OK I think, any thoughts?

Simon...

The 15B450 is an excellent driver both for 12V rigs as medium power (socket) rigs. You could use it with the magnet inside the chamber for maximum sensitivity (and still go lower as a Cubo 12).

Best regards

Cubo

Hello, i just finished 2 cubo KICKS and 4 cubo extra extended.
would like to upload the pictures here but still dont know how...

See the pictures here.... freespeakerplans.com/kunena/16-bass/2085...and-cubo-kicks#22729

I have just made 4x cubo 15's kappa pro 15lf2. I have been using 4x labs with 4xhd 15's very happy with that setup however, the clubs that I play are all in basements. Luggin labs down right angled stairs has become a real bind. Also labs work great outside or in big rooms but not so much in small clubs. Unless you are in the toilet that is. most bass there I think. I was looking for something smaller that wasn't so much long throw. But will go low. Well the cubo seemed the one. first test I wasn't so happy (always like that hey) lost alot of kick and as most of the gigs I do are djs so, really need kick. want kick. Urrrm. ? what to do. ? I want to make some cubo kicks but don't have the time for the next 2 gigs. So, I dragged out 6x mth 30's . Have seen a guy in oz using them for kicks. started out 4 way sub kick mid tweet. got lot's of combing. used endless settings no joy. gave up on the 4 way went 3 way cubos and mth on the same band off a driverack. Wow! crossed them all up to 140hz. Kick returned with vengence. I am really against using two subs designs together. usually doesn't work atall. This is a great combo. Psy trance punches just right. One of those strange things that just works maybe.. You do need to stack em rite not mouth to mouth. This has made the cubo's sound great real punchy. taken away the woof tightened up nice. Magnet in mouth by the way. so crossed 33.5hz to 140hz. bang on sound.
So mr cubo thank you very very much. Today I am a happy man. Will get on the cubo kicks soon. would like to hear how they sound.. top guy.

Which version would you recommend for this driver?
I can't seem to get you on email.
Thanks
www.pispeakers.com/Components/JBL_2226.pdf

Haven't seen an e-mail with your name on it (or the 2226 lately). That's a good driver for Cubo 15 Extended.

Best regards

Cubo

Hello,

I can't find download link

Sorry, my fault. Everything ok

Hello Mr. Cubo, i would love to know if this Driver will work in any of the Cubo 15`s and if so:
Normal, Extended or Extra Extended? Magnet in Chamber or in Horn?
How much Power could it take when highpassed @ 40Hz 18dB/oct. ?
What would the Sensitivity be like?
What would the lowest reproducible Frequency be like?

Driver: The Box Speaker 15-300/8-A

Fs: 52.6Hz
Qms: 14.00
Qes: 0.67
Qts: 0.64
Rms: 2.5kg/s
Cms: 0.09mm/N
Mms: 105.5g
BxL: 17.3 N/A
SPL: 95.2 dB
Vas: 100.3 L
Re: 5.4 Ohms
Le: 1.2mH


Datasheet: images6.static-thomann.de/pics/atg/atgda...193264_de_screen.pdf

Thanks in advance

please excuse my bad english
