heart Cubo 15

2 years 10 months ago #24842 by Buje
Replied by Buje on topic Cubo 15
Hi, i have a couple of cube 15 extended, can i use them with jbl 18sws1000? thank you, sorry google translator.

Please Log in or Create an account to join the conversation.

2 years 10 months ago #24843 by Cubo15
Replied by Cubo15 on topic Cubo 15
The jbl 18sws1000 or jbl 15sws1000? Technically both but I favor the 15".

Cubo

Please Log in or Create an account to join the conversation.

2 years 10 months ago #24845 by simon hesthaven
Replied by simon hesthaven on topic Cubo 15
Hej Cubo.
Greetings from Denmark! and great work by the way : )

Is it still possible to acquire the plans for the standard cubo15?

Simon H

Please Log in or Create an account to join the conversation.

2 years 10 months ago #24846 by Buje
Replied by Buje on topic Cubo 15
18sws1000, how should I place them, using the 15 hole or enlarging to 18? Thank you

Please Log in or Create an account to join the conversation.

2 years 10 months ago #24851 by Cubo15
Replied by Cubo15 on topic Cubo 15
@ Simon H: Last time I checked they were on the 'plans-page' freespeakerplans.com/plans/14-plans/basscab/44-cubo15

@ Buje: It will be difficult to place an 18" driver on a 17" baffle (it can be done though). I usually make a 2 part plywood ring (two rings of at least 18 mm thickness), with t-nuts embedded within it. The first ring fits the 15" bolt pattern and is large enough to fit the 18" driver, the second ring allows the 18" to make at least 18 mm of excursion (at least Xmax but preferably Xmech). The rings are glued together but the structure as a whole is removable, so you can still mount 15" drivers later.

Alternatively you can glue an 18" + diameter plywood spacer ring to the baffle directly (with t-nuts embedded within it), front mount the 18" driver on the spacer ring.

Cubo
The following user(s) said Thank You: Buje

Please Log in or Create an account to join the conversation.

2 years 9 months ago #24856 by Zambrotta
Replied by Zambrotta on topic Cubo 15
Greetings from Zimbabwe. I want to build a pair of Cubo 15 standard version and load them with p. audio blue monster bm-15w 400w speakers. I would like to find out if those speakers are suitable for those cabinets.Plizz assist

Please Log in or Create an account to join the conversation.

2 years 9 months ago #24860 by Cubo15
Replied by Cubo15 on topic Cubo 15
The T/S-parameters you send me are of the BM-15LF, whereas you mention the BM-15W here. As far as I can tell those are two different drivers, the BM-15W has substantial lower Xmax, Qts and power handling, however both are best suited for Cubo 15 Extended.

Best regards Cubo

Please Log in or Create an account to join the conversation.

2 years 9 months ago #24862 by Zambrotta
Replied by Zambrotta on topic Cubo 15
Thanks Cubo will start my build today using 16mm mdf.... cannot afford to buy birch plywood it's expensive.Wil send pics soon.

Please Log in or Create an account to join the conversation.

2 years 9 months ago #24864 by Zambrotta
Replied by Zambrotta on topic Cubo 15
hello guys the bass coming out of my cubo 15 extended is amazing am planning to build two more n load them with p. Audio p150/2226 15inch speakers

Please Log in or Create an account to join the conversation.

2 years 9 months ago #24865 by Zambrotta
Replied by Zambrotta on topic There is a Pic of the cubo 15 n 10inch tops
......
Attachments:

Please Log in or Create an account to join the conversation.
