MN-246

  • Visitor
  • Visitor
14 years 2 days ago #9823 by
Replied by on topic MN-246
nice plan but l heard that when the drives are put opposite their magnetic field is affect,. espsecillay share power

Please Log in or Create an account to join the conversation.

More
12 years 10 months ago #15944 by suzan
Replied by suzan on topic MN-246
there's horisontal sectionhow about vertical section

Please Log in or Create an account to join the conversation.

More
11 years 8 months ago #19404 by Simon Engquist
Replied by Simon Engquist on topic MN-246
is this a 2* 18 or 15

Please Log in or Create an account to join the conversation.

More
11 years 8 months ago #19405 by bgrade
Replied by bgrade on topic Re: MN-246
18. Plans say it is recomended for RCF LF18g401
www.rcf.it/products/precision-transducer...transducers/lf18g401

Please Log in or Create an account to join the conversation.

More
11 years 2 months ago #20316 by squiggs
Replied by squiggs on topic MN-246
has anyone on here tried building these? I'm considering it in the future but would like to see some build pics or at least get some verification that they work well/ are worth building first.

Please Log in or Create an account to join the conversation.

More
10 years 9 months ago #20905 by snowflake
Replied by snowflake on topic MN-246
does the slot throat on the front of the drivers actually do anything? would have thought this design would work better if you turned the speakers round sothe faced each other and angled the baffles slightly so the central chamber flares toward the mouth.

Please Log in or Create an account to join the conversation.

More
7 years 8 months ago #23719 by deejay skillz
Replied by deejay skillz on topic MN-246
Any cutlist for this plan? is a 18LFG400 a good replacement for G401?

Please Log in or Create an account to join the conversation.

More
6 years 8 months ago - 6 years 8 months ago #24184 by tasos93
Replied by tasos93 on topic MN-246
I kindly ask Marc to tell me if the paudio E18-ELF speaker goes, here are the parameters THIELE/SMALL PARAMETERS
Resonance Frequency Fs 30 Hz
DC. Resistance Re 6.0 Ω
Coil Inductance Le 1.00 mH
Mechanical Q Factor Qms 7.39
Electrical Q Factor Qes 0.47
Total Q Factor Qts 0.44
BL Product BL 21.53 Tm
Effective Moving Mass Mms 188.31 g
Equivalent Cas Air-Load Vas 263.57 Liters
Effective Piston Area Sd 0.1134 Sqm
Half-Space Efficiency Eff 1.56 %
Airgap Height Hag 8.0 mm
Voice Coil Height Hvc 23.0 mm
Voice Coil Overhang Xmax 7.5 mm
Last edit: 6 years 8 months ago by tasos93.

Please Log in or Create an account to join the conversation.
