7 years 3 months ago #16994 by Kilopa
D&B Q SERIES dispersion was created by Kilopa
Hello all, looking at the D&B Q series boxes and wondering how they achieve directivity control down to a claimed 400Hz from this configuration? The drivers are roughly facing the ends of the cabinets and this apparently achieves 'dipolar radiation' but I can't see how...
Is each driver assigned it's own amp channel and some sort of processing applied to each or is this really simple and I'm missing something??
Just interested really!

Please Log in or Create an account to join the conversation.

7 years 3 months ago #17003 by tony.a.s.s.
Replied by tony.a.s.s. on topic D&B Q SERIES dispersion
Unless you own and use some of the gear, it's unlikely that anyone will know, apart from theorizing. I would try to get hold of the specs from the web site, they might explain it in detail. D and B, whether you like the gear or not, has always had a strong technical reputation and a reason for doing things.

Peace and goodwill to all speaker builders

Please Log in or Create an account to join the conversation.

7 years 3 months ago #17009 by Kilopa
Replied by Kilopa on topic D&B Q SERIES dispersion
Thanks for the reply Tony (increasing activity on this sites forum is a good thing!) There is no real technical info even in the user manual but there are drawings of the cabinet with grille removed.. Doesn't look anything special or clever to me so just wanted peoples opinions on how it might work.. Probably DSP knowing D&B!

Please Log in or Create an account to join the conversation.

7 years 3 months ago #17020 by tony.a.s.s.
Replied by tony.a.s.s. on topic D&B Q SERIES dispersion
Yes I would have thought it would be through DSP. If they can affect the phase position and level of each speaker, they will be able to bend and limit the beam etc.

Peace and goodwill to all speaker builders

Please Log in or Create an account to join the conversation.

6 years 11 months ago #18761 by jsg
Replied by jsg on topic D&B Q SERIES dispersion
Hi all

I've been away for a while, but back now. The D&B cabs are interesting to me because my local nightclub (the Junciton in Cambridge) has them and my own TX and TY designs are similar in some ways.

D&B's user manual is actually quite forthcoming: www.dbaudio.com/fileadmin/docbase/Q10_Manual_1.4EN.PDF

I think fig 10 is the most important graph: horizontal spread in line array config. We see a reasonably controlled spread over 1K, which is the horn at the centre of the cab. Below 1K it pinches in rapidly, then expands, eventually getting omni at low freqs.

Reading off 400Hz at -6dB, I see 90 degrees total spread, which seems controlled, BUT it is trending at around 50 degrees per octave.

The graph looks like what you would expect from two sources a certain distance apart, which is probably what dipole means, and from the engineering sketch it looks like the two 10s are positioned at each end of the cab. I don't think the ducts are important, probably just a way of making the cab smaller. And I don't think DSP is needed for the directivity graphs shown.

I think they might use DSP to remove the sharp resonant peaks resulting from the ducts (TX design had this problem too). DSP *could* be used to reduce the narrowing seen in the graph by simply fading out one of the drivers, but I guess they found these results good enough. Eventually, compromises must always be made, and D&B's good reputation suggests they are probably making the right compromises.

Nonetheless I would do things differently... of course!

Ars est celare artem
