Speakon to amplifier
was created by
Klinke
Hey FSP.
I got 2 of these speakers:
www.disconetto.dk/shop/pa-hoejttaler-pab-112mk2-20995p.html
This amplifier:
www.pioneer.eu/eur/products/25/29/182/GM-D8604/specs.html
And i got 2 speakon cables with 4 wires, black, white, yellow and red.
I assume that plugin to the speaker is the original connector on the cable, but how do I connect the cable to the amplifier?
Thank you.
Please
Log in
or
Create an account
to join the conversation.
bee
Offline
Platinum Member
Less
More
Posts: 2090
Thank you received: 34
7 years 4 months ago
-
7 years 4 months ago
#22651
by
bee
Replied by
bee
on topic
Speakon to amplifier
the amp you have is a car audio amp.... not a pa amp....
you would wire it positive on amp to +1 on speakon, negative on amp to -1 on speakon. only two wires are needed...
www.elements-audio.com
www.facebook.com/pages/Element-Audio/187065531315529?ref=hl
Last edit: 7 years 4 months ago by
bee
. Reason: typo
