question-circle need help with bass box

6 years 8 months ago #20093 by speakerz
need help with bass box was created by speakerz
Hey i'm hoping someone could help me with my box design?
im using 25ml ply and want to make a bass box with my
10 inch
80 watt.
8 ohm.
30 oz.
driver, if anyone could give me a hand with getting the volume/size of the enclosure that would be great.. also I'm aware that 80watts isn't much but its all i have to work with... also i don't know i i should use a vent i have a spare one that is almost 3inch's in diameter, i'm a complete rookie so don't hate...
thanks.

Please Log in or Create an account to join the conversation.

6 years 8 months ago #20094 by bgrade
Replied by bgrade on topic need help with bass box
You need the T/S Parameters from the driver to find the ideal box volume and whether it should be vented or sealed. WinIsd would help you greatly. No worries on rookiedom.

Please Log in or Create an account to join the conversation.

6 years 8 months ago #20095 by speakerz
Replied by speakerz on topic need help with bass box
i got given the driver and all it has on it is
Blaster
10 inches
model:sp10/30.
Air suspension.
80 watt.
8 ohm.
30 oz.
philippines.
i dont have the T/S parameters... :(

Please Log in or Create an account to join the conversation.

6 years 8 months ago #20096 by speakerz
Replied by speakerz on topic need help with bass box
i have mac, cant run WinIsd fyi

Please Log in or Create an account to join the conversation.

6 years 8 months ago #20097 by bgrade
Replied by bgrade on topic need help with bass box
Yeah I can't find anything on the internet for that driver. Not even sure if it is a subwoofer so it would be hard to guess what kind of box to make. Personally I would say that if you want to experiment with it as a learning experience, I would make a sealed box. Much easier to construct than a vented box, for a first build.

I have a car sub 10 inch recommended for a sealed box with external dimensions of 438mm x 279mm x 229mm using 19mm MDF, and having an F3 of 48 hz (which is not extremely low but still improves the car sound). So internal dimensions would be 400 x 241 x 191. The internal dimensions would be the same if you use 25mm wood. Might work, might not. Will certainly make noise, just a gamble as to the quality. Impossible to tell without the speaker parameters.

Good luck.

Please Log in or Create an account to join the conversation.

6 years 8 months ago - 6 years 8 months ago #20098 by bgrade
Replied by bgrade on topic need help with bass box
Also, here is an online site for calculating sealed boxes based on the parameters I was talking about, but it won't do you any good without choosing another driver with better product infos. http://www.mh-audio.nl/ClosedBoxCalculator.asp

There are other calculators on there too for vented boxes and horns which I have found useful. Serious design programs for speakers unfortunately requires a non-mac computer. WinIsd and Hornresp are the two that I use.

Please Log in or Create an account to join the conversation.

6 years 8 months ago #20099 by speakerz
Replied by speakerz on topic need help with bass box
Thanks so much for your help I'll give your dimensions a closer look and yeah see if I could get my hands on a better driver... But at least it's a place to start.
Cheers.
