heart hog scoop 21'' desing help

4 years 6 months ago #22551 by toni_addkt
hog scoop 21'' desing help was created by toni_addkt
hi !!

i've been working in a project of 21" hog scoop with precision devices pd 2150 because I have 2 for make 2 hogs.
I got the plan of the hog scoop of this forum and scaled to 21" like an idea of somone of this forum. I show you the result better for discuss. I'd like to get I would be greatful with any help.

p.d. : in squares sections I thinked in circular sections for make more linear that is possible the cone

thanks to all !!
Attachments:

Please Log in or Create an account to join the conversation.

4 years 6 months ago #22563 by Rog Mogale
Replied by Rog Mogale on topic hog scoop 21'' desing help
The horn path will be very hyperbolic <0.5, so octo hyperbolic. Not sure this will be optimum for this design given the mouth size.

Throat has a width of 127mm, then jumps to 179mm very quickly, is there a reason for this?
The following user(s) said Thank You: toni_addkt

Please Log in or Create an account to join the conversation.

4 years 6 months ago #22564 by toni_addkt
Replied by toni_addkt on topic hog scoop 21'' desing help
first of all: I can't believe that rog mogale is giving me advice of my desing !! I have to say that I'm a big fan of your desings :ohmy: :woohoo: :woohoo:

And there is no reason of this jump of throat, I saw that and i thinked the same, and this desing gives me a very strange horn with very irregular sections. As people say, maybe I should make a more linear exponential horn?

How I was not sure of this desing,yeaterday i
I got your plan, the SUPERSCOOPER MOGAlE 21, wich is desing specially for an pd2150, and i adapted the horn in the hog scoop, then I will share this plan when I go home for show it. The result is a big box but with good an very similar hornresp SPL graph

Much thanks Rob !! (i'm going to share with my friends that I'm talking with rob mogale of my desing lolll :D :D )

Please Log in or Create an account to join the conversation.

4 years 6 months ago - 4 years 6 months ago #22567 by toni_addkt
Replied by toni_addkt on topic hog scoop 21'' desing help

that's the new desing using mogale 21 superscoop reference, and adapt for get 2'5 horn lenght. what do you think??

I know the big size but i would get a good bass against weight problem ??

Maybe I could use 18mm of ply for get it more light or 21 is strongest to avoid vibrations etc..??

too much thanks and sorry for my english :)
Attachments:

Please Log in or Create an account to join the conversation.

4 years 6 months ago #22568 by toni_addkt
Replied by toni_addkt on topic hog scoop 21'' desing help
and here the horn resp graphs, that looks much pretty than the other desing that didn't arrive to 100db spl








Please Log in or Create an account to join the conversation.

4 years 5 months ago #22570 by Rog Mogale
Replied by Rog Mogale on topic hog scoop 21'' desing help
As some have said on the other forum, its a big cab for the output and cuttoff you will get. Also so much unused internal space.

The horn path could expand behind the rear chamber, making it more exponential and using up some space. If you can't get that to work then I would go back to the hog design and play around with the expansion.

Rog.

Please Log in or Create an account to join the conversation.

4 years 5 months ago #22571 by Rog Mogale
Replied by Rog Mogale on topic hog scoop 21'' desing help


Something like this could work and would give you a 2.8 meter path length.
Attachments:
The following user(s) said Thank You: toni_addkt

Please Log in or Create an account to join the conversation.

4 years 5 months ago #22572 by toni_addkt
Replied by toni_addkt on topic hog scoop 21'' desing help
much thanks rog!!

I'm gonna try i, looks nice!! thank you for show me the way, I can't wait to go home and sketch it :cheer: :cheer: I'm lucky getting your help, now I have to work hard on it and maybe I get a good bass... or I think and wish it.

I will show you my progress, thanks again !!
