heart Hog Scoop

6 years 7 months ago #19340 by patryk1305
Replied by patryk1305 on topic Hog Scoop
Thank for quick response, but I'm just interested whether this design could actually achieve such SPL levels at these frequencies?

Please Log in or Create an account to join the conversation.

6 years 7 months ago #19341 by bgrade
Replied by bgrade on topic Hog Scoop
it would probably come close if you put in all the numbers right. Horn Resp does not take into account losses from panel vibration so it would probably lose a dB or two there, but the driver would probably shred rather quickly.

Please Log in or Create an account to join the conversation.

6 years 7 months ago #19342 by patryk1305
Replied by patryk1305 on topic Hog Scoop
Yeah I know it's only calculated SPL and thanks for all the help! :)

Please Log in or Create an account to join the conversation.

6 years 5 months ago #19647 by eastman17c
Replied by eastman17c on topic Hog Scoop
thank you

Please Log in or Create an account to join the conversation.

6 years 5 months ago #19665 by eastman17c
Replied by eastman17c on topic Hog Scoop
Hi
How to measure the S1 - S5, etc of the actual construction plan of the Hog scoop ?
i cannot get how to transformer those value to actual measurement of the plyboard. thanks

Please Log in or Create an account to join the conversation.

6 years 5 months ago #19666 by bgrade
Replied by bgrade on topic Hog Scoop
That is just the area of the throat at specific points in the horn path. If you just use the measurements on the plan, you should not go wrong, unless you are trying to modify the design, and then you will have a fair bit of math to do. I would say just stick to the plan.

Please Log in or Create an account to join the conversation.

6 years 4 months ago - 6 years 4 months ago #19804 by magic
Replied by magic on topic Hog Scoop
built one of these last year loaded with a PD184 bassline deep alot deeper than a bass bin wondering could you build 15" version

Please Log in or Create an account to join the conversation.

6 years 4 months ago #19928 by tamuks
Replied by tamuks on topic Hog Scoop
managed to built 4 and 3as shoked with the results. wanna see how 6 will sound

Please Log in or Create an account to join the conversation.

6 years 2 months ago #20190 by ronnieb
Replied by ronnieb on topic Hog Scoop
Can you use medium density fibre board for this box...I read somewhere that its better than ply...

Please Log in or Create an account to join the conversation.

6 years 2 months ago #20191 by bgrade
Replied by bgrade on topic Hog Scoop
I think MDF is denser and sounds better, but there are concerns about joints cracking under the weight of larger MDF boxes. Also, MDF is extremely moisture sensitive. If you built them for an install MDF would be fine. If you are carrying them around, I would recommend birch.

Please Log in or Create an account to join the conversation.
