Cubo12 full range

Hi everybody, hi Mr.Cubo, I just made 4 nice Cubo 12, thanks a lot for share your plans, really good sound, I load them with Fane 12-500lf cheap and solid, but now I tell you my question, because I need something on top...
I have two Fane 12-250tc full range speaker, with triple cone, now they are in two scoop bins and they are ok, nice sound and not so bad bass, but scoops are too big, even 12", so I think about your designs with kiss principles... I'm thinking about a cubo-size speaker but good for this fane 12-250tc...
I already searched in the forum about this fane full range speaker but I didn't find an answer good for my situation, so I kindly ask if someone from this forum can help me with this project.

Luigi
(in picture is my sound system)

The Fane 12-250tc is really made for one thing and that is a full range cabinet, with not enough Xmax to do much, if any bass-reinforcement on high levels. KISS in this case would mean it's put it in a closed cabinet, of about 100 litres external (so pretty much the same volume as a Cubo 12). Crossed around 100 Hz, to do mid-high for close range listening.

I can give you some more accurate internal volume if you'd like.

Best regards Cubo

yes Mr.Cubo, thank you for your fast reply, this is what I 'm looking for, a cabinet with approx. same sizes of cubo12 but good for this kind of speaker, so I can play 4 cubo12 with fane 12-500lf for bass and this 2 fane 12-250tc on top for all the rest of frequencies, a really small sound system, total 6 speakers and 2500 watt, easy to transfer everywhere just in a normal car. thank you for your help

best regards

Luigi

A cabinet of internal 57 litres, made from 15 mm sheet, with the front of the baffle 15 mm behind the front of the cabinet. External 45 cm wide, 57 cm high and 30 cm deep. If you use dampening inside the cabinet on all walls (recommended), you can make the cabinet 26,5 cm deep (instead of 30 cm).

Best regards

Cubo

Any construction plan and cut sheet for this cubo 12 full range?

Sent from my ASUS_X00DDB using Tapatalk

Any construction plan and cut sheet for this cubo 12 full range?

Sent from my ASUS_X00DDB using Tapatalk

you can made 2 box from a single 122x244, sorry if cut list is handmade

May I see the finished one?

Sent from my ASUS_X00DDB using Tapatalk

almost done

nice sound, 250watt rms, easy to transport, thank you Mr. Cubo for your help in this project
