file TC SOUNDS 5100 PRO DRIVER CUBO 18

3 years 10 months ago #23612 by innsanes
TC SOUNDS 5100 PRO DRIVER CUBO 18 was created by innsanes
I WAS WONDER IF THIS WOULD WORK FOR THE CUBO 18

TC SOUNDS 5100 PRO

TC SOUNDS 5100

Product Specifications
Nominal Diameter18"Power Handling (RMS)1,000 Watts
Power Handling (max)2000 WattsImpedance2+2 ohms
Frequency Response15 to 150 HzSensitivity94.5 dB 1W/1m
Voice Coil Diameter4"
Thiele-Small Parameters
Resonant Frequency (Fs)26.5 HzDC Resistance (Re)3.02 ohms
Voice Coil Inductance (Le)1.96 mHMechanical Q (Qms)6.9
Electromagnetic Q (Qes)0.25Total Q (Qts)0.24
Compliance Equivalent Volume (Vas)8.88 ft.³Mechanical Compliance of Suspension (Cms)1.13 mm/N
BL Product (BL)23.8 TmDiaphragm Mass Inc. Airload (Mms)287.1g
Maximum Linear Excursion (Xmax)19.05 mm
Materials of Construction
Cone MaterialFiberglassSurround MaterialCloth
Voice Coil Wire MaterialAluminumVoice Coil FormerStainless Steel
Magnet MaterialNeodymium
Mounting Information
Overall Outside Diameter18.52"Baffle Cutout Diameter16.83"
Depth11.27"# Mounting Holes8
Optimum Cabinet Size (determined using BassBox 6 Pro High Fidelity suggestion)
Sealed Volume0.77 ft.³Sealed F391 Hz
Vented Volume1.72 ft.³Vented F359 Hz
TC Sounds Pro 5100 18" Neo Subwoofer Driver
BrandTC SoundsModelPro 5100
Part Number293-674UPC844632083020
Product CategoryPro Woofers, Subwoofers & Midrange SpeakersUnit of MeasureEA
Product Rating(4 Reviews)Weight53.4 lbs.
California Prop 65
Warning: California residents only. Please note per Proposition 65 that this product may contain chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.

Please Log in or Create an account to join the conversation.

3 years 10 months ago #23614 by Cubo15
Replied by Cubo15 on topic TC SOUNDS 5100 PRO DRIVER CUBO 18
It would work in Cubo 18 Extended, however it's much more of a sub driver and would be a lot happier in Cubo Sub ;)

Best regards

Cubo

Please Log in or Create an account to join the conversation.

3 years 10 months ago #23617 by innsanes
Replied by innsanes on topic TC SOUNDS 5100 PRO DRIVER CUBO 18
thanks cubo!!

Please Log in or Create an account to join the conversation.
