file Volt rv4504 enclosures

12 years 3 months ago #1488 by JS
Volt rv4504 enclosures was created by JS
I'm thinking of putting a Volt RV4504 into a sealed box enclosure of about 110 litres net volume and using parametric equalization of 8dB at 40 Hz with a Q = 2. Does anyone have any comments or suggestions?
Edited by: JS

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1492 by tony.a.s.s.
Replied by tony.a.s.s. on topic Volt rv4504 enclosures
How have you arrived at your decisions so far?

Peace and goodwill to all speaker builders

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1495 by JS
Replied by JS on topic Volt rv4504 enclosures
I only have limited space, hence the small volume, ideal volume for a critically damped sealed box is about 220 litres, but I don't have the room. Using the eq is the only way to get a decent response. Would a cabinet of this size act as an acoustic suspension rather than an infinite baffle?

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1497 by tony.a.s.s.
Replied by tony.a.s.s. on topic Volt rv4504 enclosures
Infinite Baffle is a term used for a box where the baffle folds round and meets itself around the back. Acoustic suspension is a term used where a speaker will have specs that allow it to operate in a sealed box. I.e. a box with no tuning port. It is then impossible to tune these in a ported box. A lesson I learned whilst experimenting with Dynaudio speakers. So, are you talking about a small reflex cab that can be tuned to gain the optimum performance with your setup?

Peace and goodwill to all speaker builders

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1510 by JS
Replied by JS on topic Volt rv4504 enclosures
I was thinking of a sealed box of 110 litres with parametric eq. Could you use parametric eq with a reflex enclosure of a similar size to extend the low frequency response? Volt quote -3dB of 45 Hz in a 100 litre enclosure, could you eq this to -3dB at 35 Hz?

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1511 by csg
Replied by csg on topic Volt rv4504 enclosures
am i right in thinking this is a hifi application rather than pa? if so, your approach might work, and the reduction in max spl should not be a problem. Ithink bag end in the us uses such approaches in the design of their hifi subs.


for pa applications, i would suggest another approach such as reflex to avoid problems reaching xmax very rappidly which will happen with a sealed, eq'd system.

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1521 by deadbeat
Replied by deadbeat on topic Volt rv4504 enclosures
yes, the driver will run out of excursion if you play it low at loud volume with EQ, i think. Better to use a reflex if it's for PA.

[url=\"http://users.ece.gatech.edu/~mleach/beraneklaw.html\"]Beranek\'s law[/url]
\'bits of ply round a driver\'

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1539 by JS
Replied by JS on topic Volt rv4504 enclosures
The intended use is for hi-fi, I chose the Volt 4504 driver because Rel use Volt drivers in some of their models.

Please Log in or Create an account to join the conversation.

12 years 3 months ago #1540 by deadbeat
Replied by deadbeat on topic Volt rv4504 enclosures
I used to have a pair of REL subs... sounded great, until they died when my roof leaked. Were they sealed? I never looked around them. Good sounding boxes. The ASS Hi-Fi cabs also use Volts (I'm not sure which models)...

However, a reflex would be smaller unless you need the fast transients that sealed boxes provide. If you have so little space anyway, a 15" might be a better choice. I'm not a fan of using EQ to sort out a system, EQ should be used to optimise sound on an already good sounding speaker. Don't mind my thoughts.

[url=\"http://users.ece.gatech.edu/~mleach/beraneklaw.html\"]Beranek\'s law[/url]
\'bits of ply round a driver\'

Please Log in or Create an account to join the conversation.

12 years 3 weeks ago #4084 by rich_gale
Replied by rich_gale on topic Volt rv4504 enclosures
you wont find a better 18" woofer for your task. light cone, low fs and a xmax to die for. but why bother with an 18" in 110ltrs? i wouldnt spend te £450 on a driver unless i was gonna be making the most of it. and a 200ltr+cab is the order of the day really.in a 300ltr cabinet you will get an f3 of 34hz.at 600wrms you are gonna have xmax capabilities down to 30hz. the best thing is theMms of this driver - 1/3 lighter than the average 18" driver. Im gonna be ordering some volt 18" as soon as i pluck up the courage to spend £900!

Please Log in or Create an account to join the conversation.
